The City of Jeffersonville – Big Four Ramp Lighting

The City of Jeffersonville – Big Four Ramp Lighting

The City of Jeffersonville – Big Four Ramp Lighting

Client

City of Jeffersonville

Follow Us On

Project Description:  The City of Jeffersonville celebrated the long anticipated opening of the Big Four Ramp Project, with the completion of the handrail lighting in May, 2014.  The Big Four Bridge over the Ohio River connects the two great river cities of Jeffersonville, Indiana and Louisville, Kentucky.  The former Big Four Railroad Bridge is now being utilized as a pedestrian bridge connecting both sides of the river to walkways, parks, and recreation areas.

As pedestrians exit the bridge and journey down the gently sloping, curved ramp to Jeffersonville, they will be greeted by the Big Four Station Park, currently under construction.  The ramp further directs visitors across Pearl Street toward the many shops and restaurants of Spring Street and Riverfront Drive.  Several thousand bikers, runners, and walkers cross the bridge every day.  The City of Jeffersonville looks forward to the Big Four Bridge becoming a travel destination spot, and eagerly anticipates the enormous economic impact the city will gain as well as the recreation it will provide to residents.

The lighting project was a great success as it provides a low key and beautiful ribbon of light for visitors that descend the new pathway into Jeffersonville, Indiana.

United Consulting managed the construction inspection for the installation of the Lighting Enhancement Contract.  The project included installing maintenance lighting and conduit inside the steel box girders of the ramp as well as accent lighting on the ramp piers.  The main component of the project was the installation of custom manufactured LED lighted aluminum handrail, attached to the ramp railing and stairway tower.  To make it all work, the contractor installed 2,680 linear feet of LED lighted handrail, two miles of conduit, and 8.6 miles of wire.

Approximate Project Cost:  $1,100,000

Breadth of Services Provided:  Construction Inspection

image-29

City of Huntington Signals

City of Huntington Signals

City of Huntington Signals

Client

INDOT Fort Wayne District

Follow Us On

Project Description: Six locations along state routes within the city of Huntington were found to have sub-standard traffic signal equipment along with one location in Bluffton. Each intersection required new standard traffic signal equipment to be installed. Recent paving projects through the project intersections resulted in a desire to maintain the integrity of the new pavement. United suggested the use of wireless vehicular detection at each intersection within the city of Huntington to meet the client’s expectations. Through close coordination with a local Indiana supplier, United provided the wireless design, complete with interconnection between the intersections.

Approximate Project Cost: $1.0 million

Breadth of Services United Provided:  Survey, RW Verification, Environmental, Signal Design, Utility Coordination


191st Street Corridor Study

191st Street Corridor Study

191st Street Corridor Study

Client

Indianapolis MPO City of Westfield

Follow Us On

Project Description: The Indianapolis MPO, in partnership with the city of Westfield, commissioned United to analyze 193rd/191st Street from Eagletown Road to Moontown Road. This multi-discipline study required a holistic look at the 193rd/191st Street Corridor over a 20-year study period. The goal of the study was to assess the future traffic needs of the corridor segments and intersections and develop a programming schedule to provide guidance in planning for future improvements.

After reviewing available planning documents and traffic data, Heather was able to develop a multi-step plan for addressing current and future development along the corridor. This plan incorporated both traditional traffic volume growth through the use of a yearly growth rate, and the use of estimated future generated trips resulting from future development. Utilizing the future traffic data along each segment and at each intersection, Heather completed an operation analysis of each study intersection to determine the appropriate future improvements needed. Cost estimates were prepared for each recommended improvement and a schedule or program of future improvements was created to aid the City in planning enhancements along the corridor.

Approximate Project Cost: United Fee $100k, planning study, no construction cost

Breadth of Services United provided: Corridor Planning, ITE Trip Generation, Traffic Forecasting, Traffic Operational Analysis

image-28

Peru, Wabash, Churubusco, & Nappanee Signal Modernization

Peru, Wabash, Churubusco, & Nappanee Signal Modernization

Peru, Wabash, Churubusco, & Nappanee Signal Modernization

Client

INDOT Fort Wayne District

Follow Us On

Project Description: United’s Traffic Engineering team tackled this large bundle with intersections at four separate locations. Through coordination with INDOT Central Office ADA reviewers, District Traffic Engineers, and District Construction Engineers, United successfully completed the ADA curb ramp design without the need for a technical inquiry, keeping the project on schedule. Traffic Engineer’s proactively coordinated with a concurrent preventative maintenance contract within the city of Wabash to develop a construction sequence which eliminated rework at the intersection corners caused by the overlap in project scope.

Approximate Project Cost: $3.5 million

Breadth of Services United provided: Survey, RW Verification, Environmental, Signal Design, Railroad Coordination, Utility Coordination

smith valley

Elkhart Signal Modernization

Elkhart Signal Modernization

Elkhart Signal Modernization

Client

INDOT Fort Wayne District

Follow Us On

Project Description: Truly an all-encompassing signal project, the modernization of seven signals within the city of Elkhart required the replacement of standard signal equipment, the design of nearly 20 curb ramps, and pre-emption phasing with an adjacent railroad crossing.  Although existing signal poles were utilized in many locations, a thorough utility coordination process was required to facilitate the installation of pedestrian push buttons and eliminate overhead utility crossings within the limits of the span and catenary.  Heather used a unique approach at the intersection of SR 19 and Main Street, where a dual-arm cantilever signal structure reduced the total number of signal pole foundations at the intersection.  This method also allowed the signal service to be located in a more convenient location on the north side of the intersection.

Approximate Project Cost: $1.1 million

Breadth of Services United provided: Survey, RW Verification, Environmental, Signal Design, Utility Coordination

warsaw

Warsaw Signal Modernization

Warsaw Signal Modernization

Warsaw Signal Modernization

Client

INDOT Fort Wayne District

Follow Us On

Project Description: In addition to the modernization of seven signals within the city of Warsaw, INDOT requested United’s expertise in designing the conversion of Hickory Street to a one-way facility.  Existing as a very distinct road within the city of Warsaw, Hickory Street, is a local, two-way facility, has a heavily used railroad located within the limits of the roadway.


Services added to the contract included survey, right-of-way engineering, easement documentation, a Categorical Exclusion Level 4, additional utility coordination, and roadway design.  Through diligent coordination with various INDOT departments, the railroad, and the city of Warsaw, Heather delivered this complex project on the original letting schedule.


Approximate Project Cost: $1.45 million + $300k = $1.75 million (total both Des. No.)

Breadth of Services United provided: Survey, RW Verification, Environmental, Roadway Design, Signal Design, Utility Coordination

IMG_3496-e1647451243961

Anderson Signal Modernization

Anderson Signal Modernization

Anderson Signal Modernization

Client

City of Anderson

Follow Us On

Project Description: The city of Anderson desires to upgrade the central traffic system and modernize all 99 city-owned signals. Heather’s team completed a scoping report to prioritize the modernization schedule for the signals and determine the appropriate central system for the City’s needs, while following FHWA guidance. Improvements include new signal heads and wiring, new traffic signal cabinets and controllers, vehicle detection, and pedestrian push buttons and pedestrian signal heads where required.


Existing curb ramps will be reconstructed where required to provide ADA-compliant access. The project will replace aging signal infrastructure originally installed in 1984. In addition, the newly installed signal system will allow City signal staff to remotely monitor and diagnose issues while improving the overall operation of the system.


Approximate Project Cost: $1.2 million

Breadth of Services United provided: Survey, RW Verification, Environmental, Signal Design, Railroad Coordination, Utility Coordination

OLYMPUS DIGITAL CAMERA

SR 930

SR 930

SR 930

Client

INDOT Fort Wayne District

Follow Us On

Project Description: The added travel lanes project along SR 930 from Parnell Avenue to Crescent Avenue also resulted in the modification of four signalized intersections along the corridor.  The design speed of SR 930 required advance loop detection at the intersection of SR 930 & Anthony Blvd.; however, the close proximity of the bridge over the St. Joseph River required a more creative use of vehicle detection technologies.  To meet the client’s expectation of not altering the newly constructed bridge deck, Heather recommended the use of Microloop vehicle detection in the vicinity of the bridge.  The recommended detection technology allowed the required advance detection to be installed in advance of the signal while leaving the bridge deck untouched.

Approximate Project Cost: $6.1 million

Breadth of Services United provided: Bridge Design, Sign Design, Signal Design, Lighting Design

SAMSUNG CAMERA PICTURES

Smith Valley Road Signal

Smith Valley Road Signal

Smith Valley Road Signal

Client

City of Greenwood

Follow Us On

Project Description: This INDOT LPA project included the installation of a traffic signal and crosswalks at the intersection of Smith Valley Road and Woodman Boulevard. Right-of-way and budget constraints created a challenging design environment. The intersection is in a location of high pedestrian activity near Greenwood High School. The use of video detection replaced the traditional loop detection methods. Heather used a non-traditional strain pole configuration used in combination with the aforementioned detection system alleviated the need to acquire right-of-way and reduced project costs.

Approximate Project Cost: $140,000

Breadth of Services United provided: Survey, Environmental, Road Safety Audit, Signal Design, Utility Coordination

image-36

I-69 Major Moves 2020 Expansion Project

I-69 Major Moves 2020 Expansion Project

I-69 Major Moves 2020 Expansion Project

Client

Milestone Contractors, L.P. INDOT

Follow Us On

Project Description: The Design-Build Best Value contract to I-69 created an added travel lane in each direction to the median between State 37 Road (Exit 205) and State Road 38 (Exit 219) and a southbound lane along the shoulder between 116th Street and the new interchange at the 106th Street exit ramp.  The I-69 and Campus Parkway was converted from a traditional diamond to diverging diamond interchange.  The project widened and rehabilitated five twin bridges on I-69 and reconstructed three overpass bridges.

The state of Indiana and INDOT have a legacy of delivering Design-Build projects through a fixed scope and low bid procurement process.  The I-69 Major Moves 2020 built on this legacy and implemented the first Design-Build Best Value project procurement delivered by INDOT.  During this procurement, the project was broken into segments for evaluation which could be constructed for a fixed budget.  Additional value in the selection process was given to more completed segments.  The process allowed for elements of the scope to be changed if it was demonstrated the end product was as good or better than the original scope.

The budget established for the project was $85 million.  Additional value was recognized for being able to deliver extended length of added travel lanes to I-69.  IFA recognized the proposal delivered an extended design life for the pavement, rehabilitation of additional structures and added widening accomplished 18 percent more than was estimated within the $85 million budget.  The additional value was accomplished through:

  • The team developed efficiencies for Milestone Contractors through better maintenance of traffic which allowed for greater production.  The rehabilitation of the existing lanes was completed during nighttime lane closures.  Once rehabilitation was constructed, the widening for the added travel lanes was completed behind temporary concrete barriers separating traffic from construction.  The separation created increased safety for the traveling public and construction workers.  The increased construction production also resulted in the delivery of additional length of added travel lanes on I-69.
  • The largest innovation was the pavement design which maximized keeping the existing pavement in place and the new widened pavement section.
  • The rehabilitated pavement minimized milling of recently surfaced pavement to only what was needed to create a continuous 2% cross slope.  It resulted in keeping more of the existing pavement and resulted in a 25% increase in pavement design life.
  • The pavement widening consisted of a 14-inch HMA pavement section that exceeded the functional and structural performance thresholds.  When combined with the proposed rehabilitation strategy, the total tonnage of HMA required per linear foot is reduced from 6.41 Tons/lft to 5.03 Tons/lft, resulting in a 27% increase in the length of interstate that can be improved.

Approximate Project Cost:  $95,000,000

Breadth of Services Provided by UNITED: Topographical Survey, Roadway Design, Bridges Design, Drainage Design, Signing Design, Signals Design, and Lighting Design
